  8. DELTA PLUS DIAMOND V UP
ABS SAFETY HELMET "BASEBALL CAP" SHAPE + CHIN ATTACHMENT - ROTOR ADJUSTMENT
ABS SAFETY HELMET "BASEBALL CAP" SHAPE + CHIN ATTACHMENT - ROTOR ADJUSTMENT
ABS SAFETY HELMET "BASEBALL CAP" SHAPE + CHIN ATTACHMENT - ROTOR ADJUSTMENT
ABS SAFETY HELMET "BASEBALL CAP" SHAPE + CHIN ATTACHMENT - ROTOR ADJUSTMENT
ABS SAFETY HELMET "BASEBALL CAP" SHAPE + CHIN ATTACHMENT - ROTOR ADJUSTMENT
ABS SAFETY HELMET "BASEBALL CAP" SHAPE + CHIN ATTACHMENT - ROTOR ADJUSTMENT
BASEBALL DIAMOND V UP
BASEBALL DIAMOND V UP
BASEBALL DIAMOND V UP

DELTA PLUS DIAMOND V UP

₱949.00

DIAMOND5UP

Product images are for illustrative purposes only and may differ from the actual product.

Specifications
ABS safety helmet with innovative design. Tested in “reverse” position. Polyamide cradle: 3 fabric bands with 8 attachment points. Foam sweat band. Rotor clamping system: head size 53 to 63 cm. 2 possible positions around the head (high/low) for better comfort. Retro-reflective band. Electrical insulation 1000 VAC/1500 VDC. Sold with 4-point chinstrap.
Performance -30°C and standard EN397:2012 effective from 03/2016 production batches.
Shell material: ABS – Non-vented
Head size: 53-64 cm
Wheel ratchet – Rotor adjustment
Textile harness: PA (Polyamide) – 8 points
Jugular material: Textile – 4 points
Neckband material : Polyester
No chin
Weight: 424 g
Face shield – Accessory added to order
Harness headband material: Polyethylene
Helmet peak: Standard
Textile harness: PA (Polyamide)
Jugular points: 4 points
Mounting notch (for earmuffs fixation): Yes
Jugular chin: No chin
Integrated option: Jugular
Low temperature resistance: -30°C
High temperature resistance: +50°C
Available or replacement accessories : Badge holder – Reflective strip – Perspiration headband – Shield – Lens – Jugular – Ear protection – Jgular with chin – Mesh visor – Neck protector – Hood – Logo – Wheel-ratchet harness adjustment
Compatible product: Lens – Shield – Earmuffs
Product Use
  • Public works
  • Building
  • Finishing works / Craftsmanship
  • Light industry
  • Maintenance
  • Chemical industry
  • Oil & Gas (extraction)
  • Petrochemical
  • Power Energy
  • Storage
Protects From The Following Risks
  • Heat
  • Shock
  • Electrical
Product Highlights & User Benefits

One-D Rotor ergonomic clamping system

One-handed adjustment with or without gloves

Retro-reflective tapes

To be better seen at your workstation

Polyamide cradle : 3 fabric bands with 8 attachment points

Comfort

ABS for lighter weight and greater comfort

Features 3 textile straps with 8 fixing points for an optimal spread of weight

Adjustable from 53 cm to 63 cm for optimum comfort

Hygeine

Replaceable headband for better hygiene

Replaceable suspension for better hygiene

The removable brow pad is washable and replaceable for a perfect hygiene solution

Performance

Adjustable headband, low or top, for a safer fit and holding cap in place when moving head

Easy to Use

Reverse wearing for a maximum field of vision without a visor

Certifications and Standards

EN397:2012 + A1:2012 Protective helmets for industry

MM Molten metal spray
LD Lateral deformation
-30°C +50°C Use: Very low temperature – -30°C / +50°C
440VAC Electric insulation
EN 50365

EN50365:2002 Electrically insulating helmets for use on low voltage installations

CLASS 0 Electrically insulating helmets – Class 0
Documents
SKU: N/A Categories: , , , , , Tags: , ,

Description

ABS Safety Helmet “Baseball Cap” Shape + Chin Attachment – Rotor Adjustment

A safety helmet featuring a versatile, sporty design for upright and inverted wear is equipped with a chinstrap for better fit.

Additional information

Color

Blue, Green, Orange, Red, White, Yellow
